Активный микшерный пульт Behringer PMP4000
Active mixing console Behringer PMP4000
1600-watt 16-channel stereo mixing console with 8 mono mic/line channels, 4 stereo line channels, 3-band British channel EQ, 24-bit multi-effects processor, stereo 7-band graphic master EQ, Voice Canceller,

1600-watt 16-channel stereo mixing console with 8 mono mic/line channels, 4 stereo line channels, 3-band British channel EQs, 24-bit multi-effects, stereo 7-band graphic master EQ, Voice Canceller, surround effect, and FBQ feedback detection system.
Compact stereo mixer with integrated 2 x 800 watt stereo amplifier.
High quality class D amplifier with exceptionally high power, high acoustic efficiency and ultra light weight. Ultra compact design weighing about half that of traditional mixers of the same configuration.
16-channel mixer input section with 8 mono channels, 4 stereo channels and separate CD/Tape stereo inputs and stereo outputs.
Studio-grade stereo 24-bit multi-effects processor with 100 high-quality preset programs.
High performance instant feedback detection and precise frequency localization (FBQ) system.
8 high quality mic preamps with switchable +48 V phantom power.
Powerful and exceptionally musical 3-band EQs, switchable low-cut filters and clip indicators on all mono channels.
7-band stereo EQ in the output section of the mixer for precise frequency equalization of the monitor and main output signals.
The Voice Canceller function, which removes solo vocal parts from playing backing tracks, for karaoke applications.
3 switchable operating modes of the power amplifier: stereo, 2 mono and bridge mode.
The effect of emulating three-dimensional acoustic space.
Adjustable 2 Track stereo input for connecting external audio sources.
Multifunctional stereo pre-outs.
Ultra-efficient internally switched power supply for quiet audio path, ultra-fast transient response and low power consumption.
High quality components and exceptional structural strength.
Designed and engineered in Germany.
Specifications:
Model: Behringer EUROPOWER PMP4000
Microphone Inputs Type: XLR (balanced)
Equivalent input noise level (20Hz - 20kHz)
With 0 Ohm source impedance: -134/136 dB A-weighted
At 50 Ohm source impedance: -131.5/134 dB A-weighted
At 150 Ohm source impedance: -129/155 dB A-weighted
Frequency response: < 10 Hz - 200 kHz (-1 dB) < 10 Hz - > 200 kHz (-3 dB)
Input Sensitivity: +10 dB, +60 dB with Pad
Max. input level: +12 dBu (+10 dB Gain)
Resistance Balanced: 2.6 kOhm
Unbalanced: 1.3 kOhm
Signal to noise ratio: 109 dB / 112 dB A-weighted
Noise level (THD + N): 0.002% / 0.0018% A-weighted
Mono Line Inputs Type: 1/4" TRS (balanced)
Resistance: 20 kOhm (balanced)
Max. input level: +21 dBu
Stereo Line Inputs Type: 1/4" TS (unbalanced)
Resistance: > 3.6 kOhm (unbalanced)
Max. input level: +22 dBu
Channel Equalizers Bass: 80 Hz (+/-15 dB) Mid: 2.5 kHz (+/-15 dB) Treble: 12 kHz (+/-15 dB)
Input 2 Track Type: RCA (unbalanced)
Resistance: 3.6 kOhm
Preouts
Main Output Type: 1/4" TS (unbalanced)
Resistance: 150 Ohm (unbalanced)
Max. output level: +21 dBu
Monitor Output Type: 1/4" TS (unbalanced)
Resistance: 150 Ohm (unbalanced)
Max. output level: +21 dBu
Stereo Outputs Type: 1/4" TRS (unbalanced)
Resistance: 150 Ohm (unbalanced)
Max. output level: +21 dBu
Type: RCA (unbalanced)
Resistance: 1 kOhm (unbalanced)
Max. output level: +21 dBu
Speaker Outputs
Type: Load resistance
In Main L/R mode: 4 - 8 Ohm
Monitor/Main Mono mode: 4 - 8 Ohm
Main Mono/Main Mono: 4 - 8 Ohm
Bridge mode: 8 - 16 Ohm
digital processing
Converters: 24-bit Delta-Sigma modulation with 64x/128x oversampling
D/A dynamic range: 90dB
Sampling frequency: 46.875 kHz
Signal transit time (line in -> line out): max. 1.5 milliseconds
Max. effect time Delay: max. 5 second
Display: 7-segment LED, 2 digits
Amplifier output RMS (1% THD, "stereo" or "2 x mono")
At 8 Ohm load per channel: 300 W
At 4 Ohm load per channel: 600 W RMS (1% THD, bridged)
At 8 Ohm load per channel: 1200 W Peak (1% THD, "stereo" or "2 x mono")
At 8 Ohm load per channel: 400 W
At 4 Ohm per channel: 800 W Peak (1% THD, bridged)
At 8 Ohm load per channel: 1600 W
Power supply: 230 V~, 50 Hz
Power consumption: 1050 W
Dimensions (H x W x D): 122 x 476 x 460 mm
Weight: 10.4 kg
