Микшерный пульт Behringer XENYX QX1202USB

The Behringer XENYX QX1202USB is a portable and ultra-compact mixer that delivers pure and natural sound with twelve inputs, four high-quality XENYX mic preamps, legendary Klark Teknik reverb processor and USB interface. Superb mic preamps

The preamps offer a stunning 130 dB dynamic range with bandwidths from 10 Hz to over 200 kHz. Armed with these outstanding mic preamps, it delivers transparent, crystal-clear performance. These state-of-the-art components represent an important step in the development of audio technology, and they can easily work on their own.

Dynamic Compression

Compression severely limits the dynamic range of a signal, lowering loud sounds and boosting softer sounds to achieve sonic balance, but its application is a delicate art that many beginners and even intermediate audio technologists find difficult. With a single knob available on all mono channels, you can easily dial in the perfect amount of compression for instruments and vocals, creating powerful mixes with punch and clarity. Gain controls allow you to adjust input signal levels, and clip LED indicators warn you when the signal is too high and may be distorting.

british equalizer

The channel EQ is based on the same circuitry, allowing you to imbue signals with incredible warmth and detailed musical character.

Clark Teknik

The built-in Klark Teknik 24-bit multi-FX processor offers 100 presets, including reverb, chorus, flanger, delay, pitch shift and various multi-effects. Each channel is equipped with a post-fader FX send that you can use to send the signal to the internal FX processor or to an external processor.

Inputs

Four sets of stereo inputs, each with +4/-10 switches, used to match the sensitivity of the mixer's input to the incoming signal, help to avoid signal degradation when connecting stereo keyboards or playback devices to the mixer.

Characteristics:

Microphone inputs: 4 x XLR, balanced, discrete input

XENYX Mic Preamps: 48V phantom powered (switchable)

Microphone: EIN (EIN 20Hz to 20kHz)

0 ohm source impedance: -133dB / -137dB A-weighted

At 50 ohm source impedance: -130 dB / -134 dB A-weighted

150 ohm source impedance: -127dB / -131dB A-weighted

Frequency response: <10Hz to 150kHz (-1dB)

Frequency response: <10Hz to 200kHz (-3dB)

Gain range: +10 to +60 dB

Maximum input level: +12 dBu with +10 dB gain

Resistance: 1.9 kΩ, balanced

Signal-to-noise ratio: 107 dB / 110 dB A-weighted (0 dBu In at +22 dB gain)

Distortion (THD+N): 0.006% / 0.005% A-weighted

Line Inputs 4 x 1/4"/6.3mm TRS, balanced

Resistance: 20 kΩ balanced, 10 kΩ unbalanced

Gain range: -10 to +40 dB

Maximum input level: +21 dBu at 0 dB gain

Stereo line inputs: 4 x pairs 1/4"/6.3mm TRS, balanced

Impedance: 20 kΩ balanced, 10 kΩ unbalanced (+4 dBu operating level) / 20 kΩ balanced, 5 kΩ unbalanced (-10 dBV)

Gain switch: +4 dBu / -10 dBV

Maximum input level: +22 dBu

2-channel I/O: 1 x pair RCA, stereo, unbalanced 2-track inputs

Resistance: 19.5 kOhm

Maximum input level: +21 dBu

Output: 1 x pair RCA, stereo, unbalanced 2-track outputs

Resistance: 1 kOhm

Maximum input level: +21 dBu

Low EQ: 80Hz (±15dB)

Mid: 2.5KHz (±15dB)

High: 12 kHz (± 15 dB)

FX Send: 1 x 1/4" / 6.3mm TRS, balanced

Resistance: 120 O

Maximum output level: +21 dBu

Main Outputs: 2 x 1/4"/6.3mm TRS, balanced

Resistance: 120 ohm, balanced

Maximum output level: +21 dBu

Controller Outputs: 2 x 1/4"/6.3mm TRS, balanced

Resistance: 120 ohm (approx)

Maximum output level: +21 dBu

Headphone output 1 x 1/4" / 6.3 mm TRS, stereo, unbalanced

Resistance: 25 ohm

Maximum output level: +21 dBu, 22 ohms (+25 dBm)

FX Partition Type: Klark Teknik

Converter: 24-bit sigma-delta

Sampling frequency: 40 kHz

USB interface connector: USB Type-B

Audio: Stereo I/O

Sampling frequency: 48 kHz

Main mix at 0 dB, channel fader at 0 dB: -83 dB / -85 dB A-weighted

Mains voltage: 120 V, 60 Hz

Power consumption: 20W

Size: 50.0 x 250.0 x 248.0 mm

Weight: 1.5 kg
