The E-800 is positioned above the E-650 as the new flagship model in Accuphase's line of integrated amplifiers. The preamplifier section is equipped with a flawless Balanced AAVA volume control, while the power amplifier section is configured as an instrumentation amplifier using a six-fold parallel push-pull configuration of pure Class A driven power MOSFETs . Operating as a simple and intelligent system, the E-800 realizes sonic excellence that reaches the very essence of music.

Peculiarities:

• Integrated amplifier with fully balanced configuration from input to output
• Balanced AAVA volume control Power amplification stage configured as an instrumentation amplifier
• Six-time parallel push-pull configuration of Class A controlled power MOSFETs
• Linear Power Boost: 50W into 8 ohms, 100W into 4 ohms and 200W into 2 ohms
• 300W output into 1 ohm load (music signals)
• High damping factor 1000
• Powerful power supply with massive high efficiency toroidal transformer and large filter capacitors
• Protection circuit using MOS-FET switches

Characteristics:

• Output power: 2 x 50 watts at 8 ohms, 2 x 100 watts at 4 ohms, 2 x 200 watts at 2 ohms
• Playback frequency: 20-20000Hz
• Signal to noise ratio: more than 101 dB
• Total harmonic distortion: less than 0.01%
• Dumping factor: 1000
• Operating Mode: Pure Grade "A"
• Circuitry: Fully balanced
• Tone Control: Yes
• Inputs: 2 pairs XLR, 5 pairs RCA Line + 1 pair Tape, 1 pair RCA and XLR input to final amplifier stage
• Outputs: 1 pair RCA, 1 pair XLR pre-stage
• Speaker outputs: A and B pair
• Power Consumption: 390 Watts
• Remote control: yes
• Headphone output: Jack 6.3 mm
• Dimensions: 465 x 502 x 239 mm (WxDxH)
• Weight: 36 kg
