Tonewinner AD-5100PA+ - power amplifier 5 x 100 W. Unbalanced inputs. Power 105 W (8 Ohm), 165 W (4 Ohm). Dimensions (W x H x D), mm: 431 x 128 x 352 mm. Weight - 9.6 kg.
View all products of the brand:
Tonewinner
Tonewinner AD-5100PA+ is 5 channels amplifier that designed to use with AV or multil channel preamps for driving the ceiling channels. Power output 5x100W and it has perfect protecting circuit, low distortion and intelligent cooling system and individual signal indications.
Features
- 5 analog inputs;
- 5 signal indicators, the brightness of each LED indicator will change depending on the intensity of the output signal;
- 5 built-in amplifier modules, the output power of each channel reaches 100W (8 Ohm);
- Brushed aluminum front panel, gold-plated speaker terminals;
- Intelligent air cooling system.
Specifications
- Signal to Noise Ratio: >= 100dB (A-weighted)
- Frequency Response: 20Hz - 30kHz (+1/-3dB)
- Distortion: <= 0.01% (A-weighted)
- Output Power:
- 165W Rms (4 Ohm, 1ch, 1kHz)
- 105W Rms (8 Ohm, 1ch, 1kHz)
- Crosstalk: >= 70dB (2ch)
- Power Consumption: <= 500W
- Gain: >= 28dB
- Nominal Impedance: 8 Ohm
- Minimum EMF Field Strength: <= 100mV
- Net Weight: 9.6kg / Gross Weight: 11kg
- Device Size (W x H x D): 431 x 128 x 352 mm, Package size (W x H x D): 544 x 210 x 446 mm
| Number of channels | 5.0 |
|---|---|
| Color | Black |
