Supra MAINS BLOCK MD06-EU/SP SWITCH SPC BK

Supra MAINS BLOCK MD06-EU/SP SWITCH SPC BK Screened Mains block with surge protection, NIF-filter & Switch. The NIF (Non-Intrusive Filtering) filter is a soft RFI (radio frequency) filter that attenuates high-frequency noise that comes from a variety of modern household sources. Custom configuration is available with the ability to reduce background noise up to 40 dB! SP models are equipped with Supra surge protection, which provides protection in all three directions: from power to ground, from neutral to ground and from power to neutral. Standard surge protection, according to the manufacturer, is sufficient only for protection from power to neutral and does not protect against lightning fields. The only better way to protect equipment than Supra SP is to completely disconnect power, connections and communication with neighboring devices.

All components are manufactured in Sweden or Germany and assembled at the factory in Ljungskil, Sweden.

• Three-layer surge protection cuts out lightning and other surges in the vicinity.
• Noise reduction up to 40 dB!
• On/Off switch with high starting current 20A.
• Internal wiring made of 2.5 mm² silver-plated oxygen-free copper.
• Supports peak power of 2400 Watts at 230 Volts and 10 Amps.
• Protection for both user and equipment from various variable fields and surges.
• Can be wall mounted or placed on a flat, hard surface. Rubber feet and brackets included.
• Custom NIF filter from Ben Duncan Research in the UK.
• Shielded aluminum housing prevents electrical, electromagnetic and magnetic fields.

CONSTRUCTION

• Body: Aluminum, black.
• Standard: European standard.
• Input connector: SUPRA MCH-10 with 10A fuse, slow.
• Output connectors: 6 x SUPRA MCH-16/EU, Schuko.
• Rated current/voltage: 10A / 250V / 2400W.
• Switch: 2-pole On/Off with high inrush current 20A.
• Maximum RFI noise reduction: 40 dB, increased filtering.
• Internal wiring: Silver plated 2.5 mm² oxygen-free copper.
• Surge protection type 3: Uc = 2.5 kV (phase to neutral); 4.0 kV (phase or neutral to earth).
• Up = 2.0 kV (phase to neutral); 2.05 kV (phase or neutral to earth).
• Width and height (WxH): 90x50 mm.
• Length (L): MD06-EU/SP = 432 mm.

All network units can be ordered with or without filters for any of the sockets.

It is recommended to connect power amplifiers to an unfiltered outlet.
