4-channel DV audio base station MGX-4
Availability check
The MGX-4 DV audio receiver is designed for use with various MGX - series transmitters. Namely, it allows you to connect any two transmitters from the line: a handheld microphone in a metal case MGX-4H, a conference microphone MGX-4C, a bodypack transmitter MGX-4B.
View all products of the brand:
DV audio
Four-channel base station MGX-4 - designed for use with various MGX - series transmitters. Namely, it allows you to connect any four transmitters from the line:
- MGX-4H metal handheld microphone
- Conference microphone MGX-4С
- Bodypack transmitter MGX-4B
Specifications:
- Base station MGX-4 for MGX series UHF systems
- Reception radius: up to 50 meters (line of sight).
- Frequency range: 60-18000 Hz.
- Signal to noise ratio: 96 dB.
- THD (1 kHz): less than 0.5%.
- Temperature conditions: from -10 to 55 °C.
- Transmitter output power: (min/max): Low 3mW, High 15mW
- Synchronization with transmitters: manual + “IR”.
- Outputs: Four separate outputs with MonoJack connectors and two combined outputs with XLR/MonoJack connectors.
- Power supply: DC 12V / 850 mA power supply
- Dimensions WxHxD (mm): 410x44x205
Brand | DV audio |
---|---|
Model | MGX-4 |
Type | Четырехканальная базовая станция |
Frequency range | 60-18000 Гц |
output power | Low 3 мВт, High 15мВт |
exits | четыре раздельных выхода с разъемами MonoJack и два комбинированных выхода разъемы XLR/MonoJack |
Signal to noise ratio | 96 дБ |
Nutrition | блок питания DC 12В / 850 мА |
Radius of action | до 50 метров (прямой видимости) |
THD | (1 кГц): менее 0.5 %. |
Dimensions (W x H x D), mm | 410 х 44 х 205 |
Features | Синхронизация с передатчиками: ручная + “IR”. |
Working temperature | от -10 до 55 °C. |
