Product description In-Ear Sennheiser EK IEM G4-G personal monitoring system

The Sennheiser EK IEM G4-G is a compact stereo bodypack receiver for the EW IEM G4 series radio systems. A convenient solution for professional musicians performing live on stage.

Sennheiser has introduced a new series of fourth-generation wireless systems evolution wireless G4. New products are characterized by three main qualities that are always highly appreciated by users around the world: versatility, ease of use and safety.

Sennheiser EK IEM G4-G stereo receiver works clean: 566 - 608 MHz

Peculiarities:

Rugged bodypack receiver and rugged IE 4 in-ear monitoring headphones deliver clear audio at all frequencies for everyday use on stage.

All-metal half-rack stereo transmitter with organic LED display for total control

Easy and flexible wireless synchronization between transmitter and receiver via IR interface

Compatible with Sennheiser WSM control software for flexible frequency allocation

Up to 16 compatible channels

Bandwidth up to 42 MHz, 1680 selectable frequencies, full tunability in stable UHF band

Transmission range: up to 100 meters

High RF output power (up to 50 mW), subject to country specific laws

A rugged bodypack receiver that delivers clarity at all frequencies and is designed for everyday use on stage with the G4 monitoring in-ear headphone systems.

Equipment:

EK IEM G4 stereo receiver;

2 AA batteries;

IE 4 headphones;

brief instruction;

safety instruction;

manufacturer's declaration sheet.

Specifications:

Type: Stereo bodypack receiver for EW IEM G4 series radios;

Modulation: broadband FM;

RF range: 566 - 608 MHz;

Approximate operating range: 100m;

Number of channels: Maximum 1680 frequencies, adjustable in 25 kHz steps, 20 frequency sets, up to 16 preset channels each, no intermodulation, 6 frequency sets, up to 16 programmable channels;

Antenna connector: 2 BNC females;

Temperature range: -10 to +55°C;

Compander: Sennheiser HDX;

Signal-to-noise ratio: ≥ 90 dBA;

The width of the operating frequency band; up to 42 MHz;

The principle of the receiver: Diversity of signals;

Battery: 2 x AA batteries, 4 - 6 hours of operation;

Audio output power: 2 x 100 mW at 32 ohms;

Display: LCD.
